Pad moving big size 2 color pad printer with closed ink cup
- .Max printing area:85x380mm
- PLC operation
- With servo pad running
- With Closed ink cup
- Product description: LY-MP2-S500FS
PRODUCT INTRODUCTION
LY-MP2-S500FS is big size 2 color pad printer with closed ink cup ,it with pad moving by servo running , so that the products don’t need to be moved when printing , and printing results are precise.
PLC operation , easy to operate , high printing pressure.
Max printing area 85x380mm
, it with closed ink cup running system, can save 60% ink and 90% thinner, very environmental .
Printing items: Hoppers,balls,toys,bowls,garments,shoes,buckets, household appliances…..ETC
Specifications:
1.Model No.:LY-MP2-S500FS
2.Plate size:100x500mm
3.Ink cup size: 90mm
4.Max printing area:85x380mm
5.Printing capacity:800PCS/Hr
6.Control system:PLC
7.Air requirement:6 Bar
8.Voltage:110V/220V 50/60Hz
9.Machine size :2500x1250x1980mm
10.Machine weight:650KG
11.Packing size : L2600xW1360xH2050mm
12.Packing weight:750KG13.
13.With servo pad running
14.PLC operation
